GASW 20 FLURO Rod End - M20x1.5
GASW Series - Rod end with external thread made of free-cutting steel or heat-treatable steel, zinc-plated, with PTFE insert (maintenance-free).
For use under dynamic load. Dimensional series K - maintenance-free.
Sliding pair - chrome-plated steel/PTFE
Housing:
up to size 12: free-cutting steel: [DE 9SMnPb28K, FR S250Pb, IT CF9SMnPb28, SE 1912, GB 230M07, US 12L 13], turned
from size 14: heat-treatable steel: [DE C22, FR XC25, IT C21, SE 1450, GB 070M20, US M1023], forged
Bearing liner: free-cutting steel: [DE 9SMnPb28K, FR S250Pb, IT CF9SMnPb28, SE 1912, GB 230M07, US 12L 13] with bonded PTFE layer.
Inner ring: bearing steel: [ DE FR IT 100Cr6, SE 2258, GB 2S135, US Aisi 52100], hardened, ground, polished
Marchio
Simbolo
GASW 20
Codice produttore
#PDK03973606
Tipo
Fluro GASW - Series
Filettatura
M20x1.5
Tipo di Filettatura
Destra Maschio
Specifiche
D - Diametro esterno della testa della rotula [mm /inch]
50 / 1.97"
W - Larghezza interna dell'anello [mm /inch]
25 / 0.99"
T - Larghezza esterna dell'anello [mm /inch]
18 / 0.71"
L- Lunghezza [mm /inch]
78 / 3.07"
GM - Lunghezza filettatura [mm /inch]
47 / 1.85"
Angolo di rotazione
28°
Carico statico massimo [kN / lbs]
44.0 / 9891.59
Carico dinamico massimo [kN / lbs]
78.0 / 17535.10
Peso
348g / 0,77lbs
